Push-To-Talk Handsets

MCPTT-1

MCPTT-1 enables faster coordination with modern Push-to-Talk technology, reliable multi-network connectivity, and a familiar DMR-style handheld experience.

Tramigo MCPTT-1

Key Features

Works over 4G, 3G, 2G, LTE-M
Crystal-clear audio with low latency
AES-256 encrypted communication
Real-time GPS/BeiDou location tracking
Instant one-to-one and group calling
Long battery life for field use
Traditional rugged handheld design
Multi-network connectivity with eSIM

Network Support

GSM Band 2/3/8
WCDMA Band 1/5/8
CDMA Evdo Rev.A 800MHz
TD-SCDMA Band 34/39
TDD-LTE Band 38/39/40/41 or 38/40
FDD-LTE Band 1/3/5 or 1/2/3/5/7/8 or 1/2/4/5/7

Physical & Display

Dimension: 108*58*23 mm
1.77″ screen
128×160 LCD resolution

Navigation & Positioning

GPS supported
BeiDou supported

Audio Features

Multipath MIC switching
FM radio support

Wireless Connectivity

Wi-Fi 802.11 b/g/n

Charging & Interface

Micro USB charging

Durability & Environment

IP54 waterproof/dustproof
Operating temperature: -20°C to +50°C

Memory & Storage

512MB RAM
4GB ROM

System Platform

MSM8909 platform/project

User Interface & Controls

Custom boot/switch animation
Menu desktop layout
Physical key function definition supported
